CISCO Refurbished
- Manufacturer
- CISCO
- Condition
- Refurbished
- Availability
- In Stock
- List Price/RRP
- US$549.00
- Price
- US$100.00 Enquire
Description
CISCO867VAE-K9 is a router product provided by CISCO, a widely known supplier of networking equipment. The product is designed to meet the requirements of small offices and businesses that require high-speed internet access and secure connectivity for their network. The router is equipped with a variety of features, including 4 LAN ports, 1 WAN port, and a built-in 802.11n wireless access point for wireless devices. It provides a secure connection with VPN capabilities, which can be easily configured with the help of its web-based interface. It also boasts a firewall for added security and support for Quality of Service (QoS) for voice and video traffic. With its easy-to-use interface, users can quickly set up the router and manage their network with ease. CISCO867VAE-K9 promises high-speed internet access, security, and reliability, making it an ideal choice for businesses that require seamless connectivity for their network.
- Part Code
- CISCO867VAE-K9
- Description
- Cisco 867VAE Secure router with VDSL2/ADSL2+ over POTS
- Weight
- 3kg
- Manufacturer
- CISCO
- End of Hardware Support
- Yes (30 October 2022)
- End of Sale
- Yes (25 October 2017)
- End of Life
- Yes (26 April 2017)
- Warranty
-
Features and Benefits of Cisco 860VAE Series Routers
Expand
Features and Benefits of Cisco 860VAE Series Routers
BGP
MAC filtering and port security
QoS features that include LLQ and WFQ
NBAR and DiffServ
Improved interoperability vs. various DSL access multiplexers (DSLAMs) deployed at worldwide service providers
Multiple WAN options within the same box to allow consistent configuration across diverse deployments
VLANs that allow for secure segmentation of network resources
Cisco IOS Software command-line interface (CLI) or web-based configuration with Admin/Guest role-based access.
Cisco IOS Software Features on Cisco 860VAE Base Router Series: IP Base Feature Set
Expand
Cisco IOS Software Features on Cisco 860VAE Base Router Series: IP Base Feature Set
IP multicast and IP routing
IPv6
Routing Information Protocol Versions 1 and 2 (RIPv1 and RIPv2)
Network Address Translation (NAT)
Access control lists (ACLs)
Dynamic Host Configuration Protocol (DHCP) server, relay, and client
Dynamic Domain Name System (DNS)
DNS proxy and DNS spoofing
G.992.3 and 5 (ADSL2/2+ Annex A, B, M)
G.993.2 (VDSL2)
ATM QoS, operations, administration, and maintenance (OAM), and loopback
Packet Transfer Mode (PTM)
TX ring adjustment
Point-to-Point Protocol over ATM (PPPoA)
PPP over Ethernet (PPPoE)
Five 802.1Q VLANs
IPv6 name resolution
IPv6 statistics
IPv6 translation: Transport packets between IPv6-only and IPv4-only endpoints (NAT-PT)
Internet Control Message Protocol Version 6 (ICMPv6)
IPv6 DHCP
Secure Shell (SSH) Protocol with Secure HTTP (HTTPS)
Embedded Event Manager (EEM)
Advanced Security Feature Set on Cisco 860VAE-K9 Secure Router Series
Expand
Advanced Security Feature Set on Cisco 860VAE-K9 Secure Router Series
Ten IPsec tunnels
Easy VPN/IPsec VPN
FlexVPN including Site-Site VPN on 860VAE-W and C860VAE* models
Firewall
Cloud Web Security (Scansafe) Connector
MAC Filtering
Port Security
IPv4 VRF-Lite (Support for 4 VRFs)
Class-Based WFQ (CBWFQ)
Policy-Based Routing (PBR)
Class-Based QoS MIB
Class of service (CoS)-to-differentiated services code point (DSCP) mapping
Network-Based Application Recognition (NBAR)
DiffServ
IP service-level agreement (IP SLA)
Web Services Management Agent
System Specifications
Expand
System Specifications
512 MB (wireless routers)
512MB ( For C867VAE, C866VAE-K9, C867VAE-K9)
64 MB for Cisco 866VAE and 867VAE Base Routers
128 MB for C866VAE-W-K9 and C867VAE-W-K9 Secure Wireless Routers
128MB for C867VAE, C866VAE-K9, C867VAE-K9 Routers
Multimode VDSL2 and ADSL2/2+ over ISDN or
Multimode VDSL2 and ADSL2/2+ over basic telephone service
Secure routers: 1 GE + 4-port 10/100BASE-T with autosensing MDI/MDX
Secure Wireless routers: 2 GE + 3-port 10/100BASE-T with autosensing MDI/MDX
Secure Wireless routers: 802.11n 2.4 GHz ETSI/FCC compliant
USB port can be used for:
USB flash memory 128 MB (MEMUSB-128FT), 256 MB (MEMUSB-256FT), and 1 GB (MEMUSB 1024FT)
Cisco IOS Software boot from USB
Note: USB 2.0 port cannot be used for connecting external devices or as a console other than those specified at https://www.cisco.com/en/US/prod/collateral/modules/ps6247/product_data_sheet0900aecd80232473.html.
H x W x D = 1.75 x 9.5 x 9.0 in. (4.45 x 24.1 x 22.9 cm), 1 rack unit (1 RU)
Product dimensions, secure routers (CISCO866VAE-K9 and CISCO867VAE-K9):
H x W x D = 1.75 x 9.5 x 9.0 in. (4.45 x 24.1 x 22.9 cm), 1 RU
Weight: 5.5 lb (2.5 kg) maximum
AC input voltage: 100 to 240 VAC
Frequency: 50 to 60 Hz
Maximum output power: 60W
Output voltages: 12 VDC
47 CFR Part 15: 2006
CISPR22: 2005
EN300386: V1.3.3: 2005
EN55022: 2006
EN61000-3-2: 2000 [Inc amd 1 and 2]
EN61000-3-3: 1995 [+ amd 1: 2001]
ICES-003 Issue 4: 2004
KN 22: 2005
VCCI: V-3/2006.04
Immunity:
CISPR24: 1997 [+ amd 1 and 2]
EN55024: 1998 [+ amd 1 and 2]
EN61000: 4-3, 4-6
AS/NZS 3548
CFR 47 Part 15 Class B
EN55022 Class B
Nonoperating humidity: 5 to 95% relative humidity (noncondensing)
Nonoperating altitude: 0 to 15,000 ft (0 to 4570m)
Operating temperature
At sea level: 32 to 104°F (0 to 40°C)
Up 10,000 ft: 32 to 77°F (0 to 25°C)
Derating 2.7°F/10,000 ft (1.5°C/1000 ft)
Operating humidity: 10 to 85% relative humidity (noncondensing)
Operating altitude: 0 to 10,000 ft (0 to 3000m)
DSL Feature Specifications
Expand
DSL Feature Specifications
Dying gasp (Note: Dying Gasp is not assured on Annex M)
IEEE 802.1q VLAN tagging
VDSL2:
ITU G.993.2 (VDSL2)
997 and 998 band plans
VDSL2 profiles: 8a, 8b, 8c, 8d, 12a, 12b, and 17a
U0 band support (25–276 kHz)
Ethernet PTM mode only based on IEEE 802.3ah 64/65 octet encapsulation
DELT diagnostics mode
ADSL2/2+:
ADSL over basic telephone service with Annex A and ISDN Annex B ITU G. 992.1 (ADSL), G.992.3 (ADSL2), and G.992.5 (ADSL2+)
ADSL2+ over basic telephone service Annex M (for extended upstream bandwidth) for G.992.3 (ADSL2) and G.992.5 (ADSL2+)
Note: Annex M performance is not optimal over Annex A SKUs.
G.994.1 ITU G.hs Handshake Protocol
Reach-extended ADSL2 (G.922.3) Annex L for increased performance on loop lengths greater than 16,000 feet from central office
T1.413 ANSI ADSL DMT issue 2
DSL Forum TR-067 and TR-100 performance compliant
Inpulse Noise Protection (INP) with Extended Framing Parameters
Downstream Power Back Off (DPBO)
Fixed Firmware solution for General deployments. No ability to upgrade the Firmware on the 860VAE models (applicable to all non-Wifi models)
VDSL2 over ISDN and Basic Telephone Service DSLAM Interoperability for Cisco 866VAE and Cisco 867VAE
Expand
VDSL2 over ISDN and Basic Telephone Service DSLAM Interoperability for Cisco 866VAE and Cisco 867VAE
ADSL over ISDN DSLAM Interoperability for Cisco 866VAE
Expand
ADSL over ISDN DSLAM Interoperability for Cisco 866VAE
ADSL over Basic Telephone Service DSLAM Interoperability for Cisco 867VAE
Expand
ADSL over Basic Telephone Service DSLAM Interoperability for Cisco 867VAE
Refurbished CISCO CISCO867VAE-K9 datasheet
Download PDF
Product datasheet
Download PDF - 513.488 KB
